WH20x14HL Precision hollow shaft commercial length ca. 6m, C60

Name: WH20x14HL Precision hollow shaft commercial length ca. 6m, C60
Brand: WH20x14HL
SKU: WH20x14HL
Price: 32.07 EUR
Availability: InStock

Product No.:: WH20x14HL-cert0
Shipping time:: ca. 3-4 days (abroad may vary)
Stock:: m
Weight:: 1.25 kg per m
Minimum order:: 6

Certifikate EN10204-3.1B:

Sliding scale prices

6-7 m: per 32,07 EUR
13-25 m: per 27,58 EUR
31-55 m: per 24,69 EUR
61-85 m: per 23,73 EUR
91-115 m: per 22,13 EUR
> 115 m: per 21,81 EUR

32,07 EUR

incl. 19% tax excl. Shipping costs

Add to wish list

Ask about product

Description

WH20x14HL
Precision shaft 20h7 -Precision hollow shaft- as commercial length in C60 Ø 20 mm, length approx. 6100mm
Inner bore: appr. 14mm
Material: C60 (1.0601)
Surface hardened: HRC min. 59
Hardening depth: Rht min. 0,9mm
Straightness: max 0,2mm/m
Ground: Tolerance h6
Surface roughness: RA max 0,3
Roundness: 6µm

Sold in 6m increments only

Data sheets from WH20x14HL, technical info (if available) can be found in the Documents folder on the right.

Documents

Datasheet WH (135.44 KB)
