precision shaft around 18h7 in Cf53-chrome plated - as 1/3 commercial length approx. 2030mm
WV18-1/3HL Precision shaft 1/3 commercial length ca. 2,03m, Cf53-chrom
precision shaft around 18h7 in Cf53-chrome plated - as 1/3 commercial length approx. 2030mm

WV18-1/3HL Precision shaft 1/3 commercial length ca. 2,03m, Cf53-chrom

Product No.:
WV18-1/3HL-cert0
ca. 3-4 days ca. 3-4 days (abroad may vary)
Weight:
1.997 kg per m
Minimum order:
6
Sliding scale prices
6-7 m
per 20,03 EUR
13-25 m
per 17,24 EUR
31-55 m
per 15,43 EUR
61-85 m
per 14,82 EUR
91-115 m
per 13,82 EUR
> 115 m
per 13,63 EUR
Our standard price 22,26 EUR
Your price 20,03 EUR
You save 10%

incl. 19% tax excl. Shipping costs

Add to wish list
Ask about product
Description
WV18-1/3HL
Precision shaft 18h7 as 1/3 commercial length in Cf53-chromed Ø 18 mm, length approx. 2030mm

Material: Cf53-chrome plated (1.1213)
Surface hardened: HRC min. 59
Hardening depth: Rht min. 0,6mm
Straightness: max 0,2mm/m
Ground: Tolerance h7
Surface roughness: RA max 0,3
Roundness: 5µm

Sold in 6m increments only

Data sheets from WV18-1/3HL, technical info (if available) can be found in the Documents folder on the right.

Documents
Datasheet WV  (136.76 KB)
