precision shaft around 12h7 in Cf53-chrome plated - as half commercial length approx. 3050mm
WV12-1/2HL Precision shaft 1/2 commercial length ca. 3,05m, Cf53-chrom
precision shaft around 12h7 in Cf53-chrome plated - as half commercial length approx. 3050mm

WV12-1/2HL Precision shaft 1/2 commercial length ca. 3,05m, Cf53-chrom

Product No.:
WV12-1/2HL-cert0
Shipping time:
1 Week 1 Week (abroad may vary)
Weight:
0.888 kg per m
Minimum order:
6
Sliding scale prices
6-7 m
per 18,17 EUR
13-25 m
per 15,15 EUR
31-55 m
per 11,72 EUR
61-85 m
per 10,09 EUR
91-115 m
per 9,09 EUR
> 115 m
per 9,09 EUR
18,17 EUR

incl. 19% tax excl. Shipping costs

Add to wish list
Ask about product
Description
WV12-1/2HL
Precision shaft 12h7 as half commercial length in Cf53-chromed Ø 12 mm, length approx. 3050mm

Material: Cf53-chrome plated (1.1213)
Surface hardened: HRC min. 59
Hardening depth: Rht min. 0,6mm
Straightness: max 0,3mm/m
Ground: Tolerance h7
Surface roughness: RA max 0,3
Roundness: 5µm

Sold in 6m increments only

Data sheets from WV12-1/2HL, technical info (if available) can be found in the Documents folder on the right.


General information on surface hardened precision shafts in Cf53 hard chrome plated:

These shafts are widely used in automation technology, linear technology, mechanical engineering and drive technology.

Documents
Datasheet WV  (136.76 KB)
